MRX-009S
UHF AM RECEIVER MODULE
The MRX-009S is an on-off keyed (OOK) high per-
formance, ultra compact, long range receiver for re-
mote wireless applications. The receiver operates at
315, 390, 418, and 433 MHz, and is primarily intended
for use in part 15.231 systems. The MRX-009S is an
enhanced version of other MRX receivers with key per-
formance upgrades such as higher sensitivity (typically
6dB higher than the MRX-002) and faster recovery
from Shutdown (typically 1ms). Because an external
antenna is the only component required, the receiver
can be easily integrated with other applications. The
MRX-009S operates at low power consumption, generates low harmonic emissions and is a highly
reliable wireless link. The MRX-009S is a well designed receiver suitable for a variety of RF applica-
tions, particularly high volume OEM applications.
The MRX-009S contains two features that are not found in the MRX-009. The MRX-009S contains
a SAW filter and/or a low noise amplifier, which reduce noise and increase selectivity and sensitivity. The
MRX-009S has post-detection data filtering internal to the receiver. Additionally, one of two filter
bandwidths may be selected externally by the user. The MRX-009S comes in two versions: fixed-mode
(FX), which functions as a conventional, superhet receiver and increases selectivity and sensitivity per-
formance, and sweep mode (SWP), which sweeps a wider RF spectrum and allows the receiver to be
used with low cost, LC transmitters.
Key Features E Typical Applications
Low cost Remote controls
Commonly employed RKE frequencies Garage openers / Gate controls
Wide operating temperature range
Supports On-Off Keying
Low power consumption
Compact surface-mount packages
Data rate up to 2.0 kbps (fixed-mode,
Manchaster encoding)
Small size
Power down pin
Keyless entry
Lighting control
Periodic data transfer
Remote access
Guard patrol / Lone worker protection
Domestic / Commercial security
Fire / Security alarms
General wire elimination
No production tuning
Fast enable time
Contact Information
Radios, Inc.
1408 Center Avenue
Oostburg, WI 53070
Phone: 920-564-6622
Fax: 920-564-6630
Email: sales@radiosinc.com
